Electric Water Valve 120v
video
Electric Water Valve 120v

Electric Water Valve 120v

PU220 series
Pneumatic operated diaphragm valve
Zero pressure staring work
Brass copper bronze solenoid valve
Explosion-proof solenoid coil available

Features

Ningbo Yuxin Pneumatic Valve Co., Ltd. is one of the leading electric water valve 120v manufacturers and suppliers in China. If you're going to buy cheap electric water valve 120v, welcome to get quotation from our factory. All customized products are with high quality and competitive price.



Electric Water Valve 120v



PU220 series electric water valve 120v operated diaphragm valve Zero pressure staring work brass copper bronze solenoid valve explosion-proof solenoid coil available


Advantages:
Integrated valve body allows vertical/horizontal installation, reducing labor costs.
Modular internal components enable part replacement without full disassembly.
Certified by CE and RoHS, compliant with global safety standards.
Low-resistance flow path design reduces energy consumption.


Detailed Display



normally closed solenoid

Direct acting for fast on / off

Durable stainless Armature

Ex-proof coil are available

Good for low pressure operation

Compact and good appearance.

Direct acting diaphragm structure,can work at zero pressure.

Coil made from H class wire, thermosetting plastic encapsulating,reach IP65 protection class with plug



Ordering code



ordering code



Specifications



Provide explosion-proof solenoid coil,voltage 12VDC,24VDC,110VAC,220VAC



Model

PU220-01

PU220-02

PU220-03

PU220-04

PU220-06

PU220-08

Working Medium

Air,Water,Oil

Acting Type

Direct Acting Type

Control Style

Normal Close

Valve Body

Brass

Seal material

NBR,,VITON ,EPDM

Joint Pipe

G1/8"

G1/4"

G3/8"

G1/2"

G3/4"

G1"

Orifice(mm)

1.5

2.3

8.0

13.0

20.0

25.0

CV Value(m3/h)

0.10

0.18

1.00

4.00

8.60

11.00

Working-pressure

AC0-8.5,DC0-7.0

AC0-10,DC0-7.0

AC0-8.5,DC0-7.0

Max.Pressure Resistance

1.0MPa

Working Temperature

-10~90°C

Power consumption

22VA

Protection grade

Waterproof and dust proof



Overall dimension



product-1-1

product-1-1



Packaging & Delivery



1)YXPC Brand, Neutral or Customer's requires label

2)YXPC carton or same as the Customer's requires, export standard carton

3)All cartons should be packed into the pallets more carefully.

4)All of the productions are inspected carefully one by one by QC before delivery.

5)We usually use cartons to pack the goods together. When the product is a machine over 50kg, we use wooden or pallet packing.

1(001)



Company profile



NINGBO YUNXIN PNEUMATIC Co., Ltd is a factory professionally producing pneumatic components. The products are mainly including pneumatic air valve ,solenoid valve ,2 ways 3 ways 5 ways air solenoid valve,high pressure solenoid valve ,explosion proof solenoid valve ,Namur air valve ,pneumatic pulse valve, flow control valve ,air filter ,air filter regulator , air source treatment units, pneumatic control components, electric water valve 120v,pneumatic actuators, and pneumatic fitting accessories, etc. With reliable are widely used in such fields as metallurgy, food, textile, machinery, chemistry and electronics, etc. Since it was founded, have been pursued, integrity, quality, service principle. We adhering to the "customer first, forge ahead" business philosophy, adhere to the "customers first".
