This is the YXPC 3V410-15B 3/2 way pneumatic solenoid valve, a reliable electric air control solution for industrial pneumatic systems. It is a single coil, 3 port 2 position solenoid valve, designed for automatic on-off and direction control of compressed air flow. With a working pressure range of 1.5 to 8 kgf/cm² (21.3 to 113.3 psi), it fits most standard industrial pneumatic setups.

The valve features 1/2" NPT thread ports, ensuring easy and secure connection to air hoses and fittings. The solenoid coil supports multiple voltage options (DC12V, DC24V, AC110V, AC220V) to match different global power supply standards. The valve body is made of high-grade aluminum alloy, which is lightweight, corrosion-resistant and durable for long-term use in workshop environments.

Parameter	Details
Model	3V410-15B
Brand	YXPC
Way/Position	3/2 Way (3 Port 2 Position)
Port Size	1/2" NPT
Working Pressure	1.5 ~ 8 kgf/cm² (21.3 ~ 113.3 psi)
Operation Type	Single Coil Solenoid Operated
Available Voltage	DC12V / DC24V / AC110V / AC220V (Custom available)
Body Material	Aluminum Alloy
Seal Material	NBR
Working Temperature	-5 ~ 60 °C
Thread Type	NPT (Custom BSPP/BSPT available on request)
Weight	Approx. 0.45 kg



3/2 Way Control Design: 3 ports, 2 position switching, perfect for on-off control of single-acting pneumatic cylinders, air actuators, and other air-powered equipment.

Multiple Voltage Options: Solenoid coil supports DC12V, DC24V, AC110V, AC220V, compatible with power supply standards in different countries.

Durable Construction: High-quality aluminum alloy body with precision machining, resistant to wear and air leakage, long service life even in frequent operation.

Fast Response: High-performance solenoid coil ensures quick valve switching, stable and reliable performance for automated pneumatic systems.

Standard 1/2" Thread: 1/2" NPT port threads, compatible with most standard pneumatic fittings and hoses in the global market.

Wide Working Pressure Range: 1.5~8 kgf/cm² working pressure, suitable for most industrial pneumatic systems, from small equipment to large workshop setups.

YXPC Brand Quality: Original YXPC pneumatic solenoid valve, strict factory testing before shipment, consistent performance and reliable quality.

The namur pneumatic solenoid valve is among the most essential components of hydraulic and pneumatic machinery. They allow fluid to flow in different paths from one or more sources. Secondly, our valve bodies have a mirror finish and are not susceptible to oxidation. Finally, our products have low power consumption, fast response and long service life.
