Air Hose Pu
PE Polyethylene hose air hose tubing pneumatic system
Multi-size flexible air intake hose pe tubing air hose
Out diameter : 4mm 6mm 8mm 10mm 12mm 14mm 16mm
Inner diameter: 2.5mm 4mm 5mm, 6.5mm 6mm 8mm 10mm 12mm
Length 100m, 200m for Drinkable water air
Broken pressure : 25bar working temperature : -20°C-60° C
Features
Ningbo Yuxin Pneumatic Valve Co., Ltd. is one of the leading air hose pu manufacturers and suppliers in China. If you're going to buy cheap air hose pu, welcome to get quotation from our factory. All customized products are with high quality and competitive price.
Air Hose PU
1.Temperature Tolerance: Operational range of -25°C to 70°C (-4°F to 156°F), suitable for both cold and intermittent hot fluid applications. Sustains short-term exposure up to 100°C.
2.Pressure Resistance: Working pressure rated at 0.5–1.5 MPa, with burst pressure up to 3 MPa.
3.Chemical Compatibility: Resistant to water, gases (e.g., nitrogen), weak corrosive liquids, alcohols, oils, and most solvents. PE-HD variants additionally withstand gasoline.
4.Safety & Compliance: Physiologically inert, meeting hygiene standards for potable water systems. Excellent dielectric properties for electrical insulation applications.
| Features |
100% Virgin Material: Exclusively produced from prime-grade Linear Low-Density Polyethylene (LLDPE) pellets. Zero recycled/reclaimed content, ensuring material purity and consistent performance.
Traceable Raw Materials: Sourced from certified suppliers with full batch traceability (ISO 9001 compliant).
| How to order |
| Product Parameter |
|
Model |
PE4×2.5 |
PE6×4 |
PE8×5 |
PE10×6.5 |
PE12×8 |
|
Material |
Polyethylene |
||||
|
Working Media |
Air ,Water,Noncorrosive Oil |
||||
|
Max.Working Pressure |
0~12BAR |
||||
|
Ambient Temperature |
-20~+60 |
||||
|
Tube O.D |
4 |
6 |
8 |
10 |
12 |
|
Tube I.D |
2.5 |
4 |
5 |
6.5 |
8 |
|
Standard Length(m) |
200 |
200 |
100 |
100 |
100 |
|
Min.Bending Radius |
10 |
15 |
20 |
25 |
37 |
|
Broken Pressure(kgf/cm²) |
30 |
35 |
40 |
30 |
30 |
|
Model |
PE10×8 |
PE8×6 |
PE12×10 |
PE14×10 |
PE16×13 |
PE16×12 |
|
Working Media |
Air ,Water,Noncorrosive Oil |
|||||
|
Max.Working Pressure |
0~10BAR |
0~8 BAR |
||||
|
Ambient Temperature |
-20~+60 |
|||||
|
Tube O.D |
10 |
8 |
12 |
14 |
16 |
12 |
|
Tube I.D |
8 |
6 |
10 |
10 |
13 |
12 |
|
Standard Length(m) |
100 |
100 |
100 |
50 |
50 |
50 |
|
Min.Bending Radius |
35 |
20 |
37 |
56 |
60 |
60 |
|
Broken Pressure(kgf/cm²) |
24 |
24 |
24 |
20 |
18 |
20 |
| Product Show |
 |
 |
 |
| About us |
Core Products:
As a professional pneumatic components manufacturer, we produce:
Directional Control Valves (2/3/5-way solenoid valves)
Specialized Valves (High-pressure/Explosion-proof/Namur solenoid valves)
Pneumatic Pulse Valves & Flow Control Valves
Air Preparation Units (Filters, Regulators, FRL Combinations)
Pneumatic Actuators & Control Components
Pneumatic Hose & Fitting Accessories
Industry Applications:
Our ISO-certified products are extensively applied in:
✔ Metallurgical Engineering
✔ Food Processing Systems
✔ Textile Machinery
✔ Industrial Automation
✔ Chemical Processing
✔ Electronic Manufacturing
Corporate Philosophy:
Founded on the principles of integrity and excellence, we uphold:
• Quality Commitment: Rigorous ISO quality control standards
• Service Principle: 24/7 technical support and customized solutions
• Business Ethos: "Customer-Centric Innovation" as our core philosophy
Certifications & Compliance:
All products meet CE, RoHS, and ATEX standards for global market requirements.
R&D Capability:
Dedicated 15% annual revenue to pneumatic technology innovation with 28 patented solutions.
| FAQ |
Q1. Is sample order acceptable?
A: Yes,it is ok.Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order
Q2 .Whether you could make our brand on your products?
A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
Q3.How to guarantee the quality of your products?
A: Strict detection during production and Strict sampling inspection on products before shipment and intact product packaging ensured.
Q4.How to place the order?
A: You can send us email
Q5.How to make the payment?
A: We accept Bank T/T
Q6. Is there cheap shipping cost to import to our country?
A: For small order,express will be best.And for bulk order,sea ship way is best but take much time. For urgent orders,we suggest to ship by air.
Q7.Can we make customized product for air hose?
A: Yes, we are good at making customized products.
